Lyolab MINI

Lyolab MINI has the same production characteristics as Coolvacuum’s pilot equipment LyoLab, but reduced dimensions.

• Chamber material: AISI 316L stainless steel.
• Ice condenser temperature: -85˚C.
• Ice condenser capacity: 6 kg (5 kg / 24 hours).
• Overall dimensions (W x D x H): 640 x 630 x 1,655 mm.
• Shelves temperature range: -50˚C to + 70˚C.
• Heating power supply: 180 W.
• Vacuum pump output: 12 m³/h.
• Weight: 250 kg.

• Hot gas defrosting system.
• Coolvacuum Trend software for batch / cycle data logging.
• SCADA software to process production data acquisition in accordance with FDA 21CFR part 11.
• Remote connection.
• Vacuum control for cycle optimization.
• Chamber / condenser isolation valve.
• Organic solvent condenser.
• Gas discharge filter for the vacuum pump.
• Infinite condenser for continuous freeze drying.
