Beta Container

ABC Transfer® Beta Container

Reduced risks of contamination during loading and unloading

Reusable beta container making connection at your fingertips with the revolutionary EasyGlide™ seal. ABC Transfer® beta parts  are compatible with alpha parts of other brands.

Main features

Innovative designs:

  • Ergonomic handles for easy connection from the bottom of beta container.
  • No bearings. No mechanical jamming.
  • Reduced footprint in washers and steam sterilizers.
  • Replaceable connection lugs reduces the life cycle cost.


EasyGlide™ seal:

  • US FDA 21 CFR  & USP class VI compliant silicone.
  • Reduced area of ring of concern by 70%.
  • Reduced torque and particles generation during connection by rotation.
  • Designed for CIP/SIP, i.e. nor water retention nor hidden area on internal surface.


Key performance:

  • Available in DN 105, 190, 270 mm.
  • Class 1 leak-tightness as per ISO 10648-2.
  • Surface roughness, Ra ≤ 0.5 µm, as per ISO 1302.
  • Rounded shapes and edges for the ease of manual and/or automatic cleaning of external surface.

Options

  • Pressure cover for steam Sterilization-In-Place (SIP) and/or Sterilization-Out of-Place (SOP).
  • Dummy beta container for H2O2 bio-decontamination.
  • Modular basket with or without  drawer for solid transfer, e.g.  tools, fitting, or parts.
  • User-defined length of beta container for solid transfer.
  • Unser-defined configuration for liquid and/or gas transfer.
