LyoEpic

The LyoEpic range includes mobile equipment with increased number of features and configuration possibilities to use in laboratories and as pilot equipment.

• Ice condenser temperature: -55˚C / -85˚C.
• Ice condenser capacity: 18 kg (8 kg / 24 hours).
• Overall dimensions (W x D x H): 540 x 630 x 970 mm.
• Electrically heated shelves: Optional.
• Vacuum pump output: 12 m³/h.
• Weight: 95 / 120 kg.


• Hot gas defrosting system.
• Dara-Lyo Trend software for batch / cycle data logging.
• SCADA software to process production data acquisition in accordance with FDA 21CFR part 11.
• Remote connection.
• Vacuum control for cycle optimization.
• Chamber / condenser isolation valve.
• Organic solvent condenser.
• Gas discharge filter for the vacuum pump.
• Infinite condenser for continuous freeze drying.
