LyoMicron

Laboratory freeze dryers, model LyoMicron, have been specially designed for freeze-drying tests during the conceptual phase or freeze-drying of low value-added products in small batches.

• Ice condenser temperature: -55˚C / -85˚C.
• Ice condenser capacity: 7 kg (5 kg / 24 hours).
• Overall dimensions (W x D x H): 420 x 630 x 380 mm.
• Electrically heated shelves: Optional.
• Vacuum pump output: 6 m³/h.
• Weight: 65 / 85 kg.


• Hot gas defrosting system.
• Coolvacuum Trend software for batch / cycle data logging.
• SCADA software to process production data acquisition in accordance with FDA 21CFR part 11.
• Remote connection.
• Vacuum control for cycle optimization.
• Chamber / condenser isolation valve.
• Organic solvent condenser.
• Gas discharge filter for the vacuum pump.
• Infinite condenser for continuous freeze drying.
